FANUC POWER MATE 0 Operators manual Page 490

Operators manual

Page of 492

/ 492

B-63444EN/01-4

12/ 14

EDIT

DATE DESIG. DESCRIPTION

FANUC Power Mate 0 Operator’s Manual

Addition of Tool geometry and wear offset

TITLE

DRAW.NO.

CUST.

SHEET

011129 New design

Replace the description of "

•

11.4.1 Offset Number and Offset Value" with the following.

11.4.1

Setting and Displaying

the Tool Offset Value

Procedure for setting and displaying the tool offset value and the tool nose radius

compensation value

Press function key

OFFSET

SETTING

Press chapter selection soft key

[OFFSET]

or press

OFFSET

SETTING

several times until the

tool compensation screen is displayed. Different screens are displayed

depending on whether tool geometry offset, wear offset, or neither is applied.

OFFSET O0001N0001

N o. X Z R T

001 0.000 10.000 0.000 0

002 0.000 10.000 0.000 1

003 3.000 0.000 0.000 2

004 2.000 5.000 0.000 4

005 0.000 3.000 2.000 0

006 4.000 1.000 0.000 3

007 0.000 5.000 0.000 0

008 0.000 0.000 0.000 0

ACTUAL POSITION (RELATIVE)

U 0.000 W 0.000

MDI *** *** *** 16:07:17

[

OFFSET ][SETTING][ W ORK ][ ] [ (OPRT) ]

Without tool geometry/wear offset

OFFSET

GEOMETORY O0001N0001

N o. X Z R T

001

0.000 10.000 0.000 0

002 0.000 10.000 0.000 1

003 3.000 0.000 0.000 2

004 2.000 5.000 0.000 4

005 0.000 3.000 2.000 0

006 4.000 1.000 0.000 3

007 0.000 5.000 0.000 0

008 0.000 0.000 0.000 0

ACTUAL POSITION

RELATIVE

U 0.000 W 0.000

MDI *** *** *** 16:07:17

[ WEAR ][

GEOM ][ ][ ] [ (OPRT)]

With tool geometry offset

Dedicated screens are provided for displaying and setting tool offset

values and tool nose radius compensation values

Procedure for

CRT/MDI
