OPERATION

8. DATA INPUT/OUTPUT

B–63444EN/01

280

⋅ In entire program input, all lines of a program are appended, except for

its O number.

⋅ When canceling additional input mode, press the reset key or the [CAN]

or [STOP] soft key.

⋅ Pressing the [CHAIN] soft key positions the cursor to the end of the

registered program. Once a program has been input, the cursor is

positioned to the start of the new program.

⋅ Additional input is possible only when a program has already been

registered.

No. Description

The size of memory is not sufficient to store the input pro-

grams

An attempt was made to store a program with an existing pro-

gram number.

The verification operation found a mismatch between a pro-

gram loaded into memory and the contents of the program on

the floppy.

Alarm
