FANUC Power Mate 0 Operator’s Manual

ADDITION OF CANNED CYCLE AND

MULTIPLE REPETITIVE CYCLE

B-63444EN/01-3

17 / 28

EDIT

DATE DESIG. DESCRIPTION

TITLE

DRAW.NO.

CUST.

SHEET

011129 New design

As shown in the figure below, this cycle is the same as G71 except that

cutting is made by a operation parallel to X axis.

Fig. 13.2.2 (a) Cutting Path in Stock Removal in Facing

Signs of specified numbers

The following four cutting patterns are considered. All of these cutting

cycles are made parallel to X axis and the sign of ∆u and ∆w are as follows:

Fig. 13.2.2 (b) Signs of Numbers Specified with U and W in Stock

Removal in Facing

The tool path between A and A′ is specified in the block with sequence

number "ns" including G00 or G01, and in this block, a move command in the

X axis cannot be specified. The tool path between A′ and B must be steadily

increasing and decreasing pattern in both X and Z axes. Whether the cutting

along AA′ is G00 or G01 mode is determined by the command between A and

A′, as described in item 13.2.1.

13.2.2

Stock Removal in

Facing (G72)

∆U/2

∆d

Program command

Tool

ath

(F)

(R)

45°

(R)

(F)

∆w

G72 W(∆d) R(e) ;

G72 P(ns) Q(nf) U(∆u) W(

∆w) F(f)

S(s) T(t) ;

The meanin

s of ∆d, e, ns, nf, ∆u, ∆w, f, s, and t are the same as those in G71.

U(+)…

……

…W(-)…

……

…

U(+)…

……

…W(+)…

……

…

U(-)…

……

…W(-)…

……

…

U(-)…

……

…W(+)…

……

…

Both linear and circular

interpolation are possible
