FANUC POWER MATE 0 Operators manual Page 486

Operators manual

Page of 492

/ 492

B-63444EN/01-4

8/ 14

EDIT

DATE DESIG. DESCRIPTION

FANUC Power Mate 0 Operator’s Manual

Addition of Tool geometry and wear offset

TITLE

DRAW.NO.

CUST.

SHEET

011129 New design

•

Canceling tool position

offset with T00

When the tool geometry / wear compensation option is selected

(1)LGN = 0

LGN (No.5002#1) LGT (No.5002#4) LGC (No.5002#5) LWM(No.5002#6)

The geometry offset

number is:

0: Same as the wear offset

number

1: Same as the tool

selection number

Geometry compensation

is applied:

0: Based on shift of the

coordinate system

1: Based on movement of

the tool

The geometry offset is:

0: Not canceled with

T00

1: Canceled with T00

Tool position offset is

applied:

0: By means of T

code

1: By means of

movement along

axis

Result

LGC=0 Not canceled

LGT=0

LGC=1

LWM is unrelated.

Canceled

LWM=0 Canceled

LGN=0

LGT=1 LGC is unrelated.

LWM=1 Not canceled

(2)LGN = 1

LGN(5002#1) LGT(5002#4) LGC(5002#5) LWM(No.5002#6)

The geometry offset

number is:

0: Same as the wear offset

number

1: Same as the tool

selection number

Geometry compensation

is applied:

0: Based on shift of the

coordinate system

1: Based on movement of

the tool

The geometry offset is:

0: Not canceled with

T00

1: Canceled with T00

Tool position offset is

applied:

0: By means of T

code

1: By means of

movement along

axis

Result

LGT=0 LGC is unrelated. LWM is unrelated. Canceled

LWM=0

Canceled

LGN=1

LGT=1 LGC is unrelated.

LWM=1

Not canceled

Whether specifying T00 alone, while tool position offset is applied, cancels

the offset depends on the settings of the following parameters:

NOTE

1 When LGT=0, LWM is unrelated.

2 When LGT=1, LGC is unrelated, even when LGN = 0.

NOTE

1 When LGT = 0, LWM is unrelated.

2 When LGT = 1, LGC is unrelated.
