B–63503EN–1/01

3. MANUAL OPERATION

123

7100

#6 #5 #4

HPF

#3 #2 #1

THD

JHD

[Data type] Bit

JHD Manual handle feed in JOG mode or incremental feed in the manual

handle feed

0: Invalid

1: Valid

THD Manual pulse generator in TEACH IN JOG mode

0: Invalid

1: Valid

HPF When a manual handle feed exceeding the rapid traverse rate is issued,

0: The rate is clamped at the rapid traverse rate, and the handle pulses

corresponding to the excess are ignored. (The graduations of the

manual pulse generator may not agree with the distance the machine

has traveled.)

1: The rate is clamped at the rapid traverse rate, and the handle pulses

corresponding to the excess are not ignored, but stored in the CNC. (If

the rotation of the manual pulse generator is stopped, the machine

moves by the distance corresponding to the pulses preserved in the

CNC, then stops.)

7102

#6 #5 #4 #3 #2 #1 #0

HNGx

[Data type] Bit axis

HNGx Axis movement direction for rotation direction of manual pulse generator

0: Same in direction

1: Reverse in direction

7110 Number of manual pulse generators used

[Data type] Byte

[Valid data range] 1, 2, or 3

This parameter sets the number of manual pulse generators.

7113 Manual handle feed magnification m

[Data type] Word

[Unit of data] One time

[Valid data range] 1 to 127

This parameter sets the magnification when manual handle feed

movement selection signal MP2 is on.
