6. INTERPOLATION FUNCTION

B–63503EN–1/01

206

NOTE

1 This parameter is effective only in linear and circular

interpolation. In polar coordinate and cylindrical,

interpolation, the maximum feedrate for all axes specified in

parameter No. 1422 is effective.

2 If the setting for each axis is 0, the maximum feedrate

specified in parameter No. 1422 is applied to all axes and

the feedrate is clamped at the maximum feedrate.

3402

#6 #5 #4 #3 #2 #1 #0

G01

[Data type] Bit

G01 Mode entered when the power is turned on or when the control is cleared

0: G00 mode (positioning)

1: G01 mode (linear interpolation)

No. Message Description

011

NO FEEDRATE COMMAN-

DED

Cutting feedrate was not commanded or

the feedrate was inadequate. Modify the

program.

OPERATOR’S MANUAL

(For Machining Center)

(B–63514EN)

LINEAR INTERPOLATION (G01)

OPERATOR’S MANUAL

(For Lathe) (B–63504EN)

LINEAR INTERPOLATION (G01)

Alarm and message

Reference item
