11. PROGRAM COMMAND
B–63503EN–1/01
572
[Classification] Output signal
[Function] Reports that the system is in tapping mode.
[Output condition] The signal is set to 1 when:
– The system is in tapping cycle mode.
G74, G84: M series
G84, G88: T series
– The system is in tapping mode.
G63: M series
The signal is set to 0 when:
– The system is in neither tapping cycle mode nor tapping mode.
– A reset or emergency stop is specified.
#7 #6 #5 #4 #3 #2 #1 #0
F001 TAP
#7 #6 #5 #4 #3 #2 #1 #0
5101
M5B
M5T
M5T RD2 RD1
ILV RTR
EXC
FXY
FXY
[Data type] Bit
FXY The drilling axis in the drilling canned cycle is:
0 : Always the Z–axis
1 : The axis selected by the program
NOTE
In the case of the T system, this parameter is valid only for
the drilling canned cycle in the FS10/11 format.
EXC G81
0 : Specifies a drilling canned cycle
1 : Specifies an external operation command
RTR G83 and G87
0 : Specify a high–speed peck drilling cycle
1 : Specify a peck drilling cycle
ILV Initial point position in drilling canned cycle
0 : Not updated by reset
1 : Updated by reset
Signal
Tapping signal
TAP <F001#5>
Signal address
Parameter
