Series 0i - Model A Connection manual (Function) Page 659

Connection manual (Function)
B–63503EN–1/01
12. DISPLAY/SET/EDIT
643
NOTE
4 The following table lists the override values which can be
selected by soft switches for jog feedrate.
*JV00 – *JV150 (*JV0 – *JV150)
15 12
±±
8
±
4
±
0
±
bit
Override
values (%)
0 1111 1111 1111 1111 0
1 1111 1111 1111 0 1 0 1 0.1
2 1 1 1 1 1 1 1 1 1 1 1 1 0 0 0 1 0.14
3 1 1 1 1 1 1 1 1 1 1 1 0 1 0 1 1 0.2
4 1 1 1 1 1 1 1 1 1 1 1 0 0 1 0 0 0.27
5 1 1 1 1 1 1 1 1 1 1 0 1 1 0 1 0 0.37
6 1 1 1 1 1 1 1 1 1 1 0 0 1 0 1 1 0.52
7 1 1 1 1 1 1 1 1 1 0 1 1 0 1 1 1 0.72
8 1 1 1 1 1 1 1 1 1 0 0 1 1 0 1 1 1.0
9 1 1 1 1 1 1 1 1 0 1 1 1 0 0 1 1 1.4
10 1 1 1 1 1 1 1 1 0 0 1 1 0 1 1 1 2.0
11 1 1 1 1 1 1 1 0 1 1 1 1 0 0 0 1 2.7
12 1 1 1 1 1 1 1 0 1 0 0 0 1 1 0 1 3.7
13 1 1 1 1 1 1 0 1 1 1 1 1 0 1 1 1 5.2
14 1 1 1 1 1 1 0 1 0 0 1 0 1 1 1 1 7.2
15 1 1 1 1 1 1 0 0 0 0 0 1 0 1 1 1 10.0
16 1 1 1 1 1 0 1 0 1 0 0 0 0 1 1 1 14.0
17 1 1 1 1 1 0 0 0 0 0 1 0 1 1 1 1 20.0
18 1 1 1 1 0 1 0 1 0 1 1 1 0 0 1 1 27.0
19 1 1 1 1 0 0 0 1 1 0 0 0 1 0 1 1 37.0
20 1 1 1 0 1 0 1 1 1 0 1 0 1 1 1 1 52.0
21 1 1 1 0 0 0 1 1 1 1 0 1 1 1 1 1 72.0
22 1 1 0 1 1 0 0 0 1 1 1 0 1 1 1 1 100.0
23 1 1 0 0 1 0 0 1 0 1 0 0 1 1 1 1 140.0
24 1 0 1 1 0 0 0 1 1 1 0 1 1 1 1 1 200.0
