Series 0i - Model A Connection manual (Function) Page 681

Connection manual (Function)

Page of 874

/ 874

B–63503EN–1/01

13. INPUT/OUTPUT OF DATA

665

(1) Parameters common to all channels

ENS0100

#6 #5 #4 #3

NCR

#2 #1

CTV

Setting entry is acceptable.

[Data type] Bit type

CTV Character counting for TV check in the comment section of a program.

0 : Not performed

1 : Performed

NCR Output of the end of block (EOB) in ISO code

0 : LF, CR, CR are output.

1 : Only LF is output.

ENS Action taken when a NULL code is found during read of EIA code

0 : An alarm is generated.

1: The NULL code is ignored.

(2) Parameters for channel 1 (I/O CHANNEL=0)

NFD0101

#6 #5 #4 #3

ASI

#2 #1 #0

SB2

[Data type] Bit type

SB2 The number of stop bits

0 : 1 bit

1 : 2 bits

ASI Code used at data input

0 : EIA or ISO code (automatically distinguished)

1 : ASCII code

NFD Feed before and after the data at data output

0 : Output

1 : Not output

NOTE

When input/output devices other than the FANUC PPR are

used, set NFD to 1.

0102

Number specified for the input/output device

(when the I/O CHANNEL is set to 0)

[Data type] Byte

Set the number specified for the input/output device used when the I/O

CHANNEL is set to 0, with one of the set values listed in Table 13.1 (a).
