Series 0i - Model A Connection manual (Function) Page 839

Connection manual (Function)
B–63503EN–1/01
A. INTERFACE BETWEEN CNC AND PMC
823
Function Section
M
series
T
series
AddressSymbolSignal name
Auxiliary function
Auxiliary function lock signal AFL G005#6 f f
Auxiliary function
lock
Auxiliary function lock check signal MAFL F004#4 f f
8.2
Polygonal turning
Polygon synchronization under way
signal
PSYN F063#7 f —
6.9
All–axis machine lock signal MLK G044#1 f f
Machine lock Each–axis machine lock signal MLK1 to MLK4 G108 f f
5.3.1
All–axis machine lock check signal MMLK F004#1 f f
Manual absolute
Manual absolute signal *ABSM G006#2 f f
Manual absolute
on/off
Manual absolute check signal MABSM F004#2 f f
5.4
SWS1 G027#0 f —
Spindle selection signals
SWS2 G027#1 f —
Multi–spindle control
(T series)
*SSTP1 G027#3 f —
9.9
(T series)
Individual spindle stop signals
*SSTP2 G027#4 f —
Gear selection signals (input) GR21 G029#0 f —
2nd position coder selection signal PC2SLC G028#7 f —
Multi–spindle control
(T series)
ENB2 F038#2 f —
9.9
(T series)
Spindle enable signals
ENB3 F038#3 f —
Mirror image signals MI1 to MI4 G106 f f
Mirror image
Mirror image check signals MMI1 to MMI4 F108 f f
1.2.5
Memory protection
key
Memory protection signals KEY1 to KEY4 G046#3 to #6 f f
12.2.3
Mode selection signals MD1, MD2, MD4 G043#3 to #2 f f
Manual data input selection check
signal
MMDI F003#3 f f
Automatic operation selection check
signal
MMEM F003#5 f f
Mode selection
Memory edit selection check signal MEDT F003#6 f f
2.6
Mode selection
Manual handle feed selection check
signal
MH F003#1 f f
2.6
Incremental feed selection check signal MINC F003#0 f f
Jog feed selection check signal MJ F003#2 f f
TEACH IN selection check signal MTCHIN F003#7 f f
RGTAP G061#0 f f
Rigid tapping signal
RGSPP F065#0 — f
Rigid tapping Spindle rotation direction signals RGSPM F065#1 — f
9.10
Rigid tapping–in–progress signal RTAP F076#3 f f
Rigid tapping spindle selection signals RGTSP1, RGTSP2 G061#4, #5 f —
