11. PROGRAM COMMAND
B–63503EN–1/01
598
#7
8132
#6 #5
SCL
#4 #3 #2 #1 #0
NOTE
When this parameter has been set, the power must be
turned off before operation is continued.
[Data type] Bit
SCL Specifies whether to use scaling, as follows :
0 : Not to use.
1 : Use.
NOTE
It is impossible to select the small–hole peck drilling cycle
and scaling functions at the same time.
#7 #6 #5 #4 #3 #2 #1 #0
SCR5400 XSC
[Data type] Bit
XSC Axis scaling and programmable mirror image
0 : Invalidated (The scaling magnification is specified by P.)
1 : Validated
SCR Scaling magnification unit
0 : 0.00001 times (1/100,000)
1 : 0.001 times
#7 #6 #5 #4 #3 #2 #1 #0
5401 SCLx
[Data type] Bit axis
SCLx Scaling for every axis
0 : Invalidated
1 : Validated
Parameter
D Setting valid/invalid and
magnification of scaling
D Valid/invalid setting to
each axis scaling
