5. AUTOMATIC OPERATION

B–63503EN–1/01

178

[Classification] Input signal

[Function] Enables single block operation.

[Operation] When this signal is set to 1, single block operation is performed. When

this signal is set to 0, normal operation is performed.

[Classification] Output signal

[Function] Notifies the PMC of the state of the single block signal.

[Output condition] This signal is set to 1 in the following case:

– When single block signal SBK is set to 1

This signal is set to 0 in the following case:

– When single block signal SBK is set to 0

#7 #6 #5 #4 #3 #2 #1 #0

G046

F004

SBK

MSBK

6000

#6 #5

SBM

#4 #3 #2 #1 #0

[Data type] Bit

SBM Custom macro statement

0: Not stop the single block

1: Stops the single block

NOTE

SBM is invalid when NOP (bit 0 of parameter No. 3404) is

set to 1.

Signal

Single block signal

SBK <G046#1>

Single block check signal

MSBK <F004#3>

Signal address

Parameter
