Series 0i - Model A Connection manual (Function) Page 506

Connection manual (Function)

Page of 874

/ 874

B–63503EN–1/01

9. SPINDLE SPEED FUNCTION

490

#7 #6 #5 #4 #3 #2 #1 #0

5204 DGN

NOTE

When this parameter is set, the power must be turned off

before operation is continued.

[Data type] Bit

DGN On the diagnosis screen:

0 : A rigid tapping synchronization error is displayed. (Nos. 455 to 457)

1 : An error difference between the spindle and tapping axis is displayed.

(Nos. 452 and 453)

5210 Rigid tapping mode specification M code

[Data type] Byte

[Valid data range] 0 to 255

This parameter sets an M code that specifies the rigid tapping mode.

To set an M code larger than 255, set it to parameter No. 5212.

NOTE

The M code is judged to be 29 (M29) when “0” is set.

5211 Override value during rigid tapping extraction

[Data type] Byte

[Unit of data] 1 %

[Valid data range] 0 to 200

The parameter sets the override value during rigid tapping extraction.

NOTE

The override value is valid when DOV in parameter No.

5200#4 is “1”.

5212 M code that specifies a rigid tapping mode

[Data type] Two–word

[Unit of data] Integer

[Valid data range] 0 to 65535

This parameter sets the M code that specifies the rigid tapping mode.

The M code that specifies the rigid tapping mode is usually set by

parameter 5210. To use an M code whose number is greater than 255,

specify the code number with parameter 5212.
