Series 0i - Model A Connection manual (Function) Page 153

Connection manual (Function)

Page of 874

/ 874

B–63503EN–1/01

4. REFERENCE POSITION ESTABLISHMENT

137

< Conditions >

D When there is a remaining distance to travel.

D When an auxiliary function (miscellaneous function, spindle–speed

function, tool function) is being executed.

D When a dwell or cycle such as a canned cycle is being executed.

1821 Reference counter size for each axis

NOTE

When this parameter has been set, the power must be

turned off before operation is continued.

[Data type] Two–word axis

[Valid data range] 0 to 99999999

Set the size of the reference counter.

As the size of the reference counter, specify the grid interval for the

reference position return in the grid method.

Size of the reference counter =

grid interval

detection unit

Grid interval = the amount of travel per rotation of the pulse coder

1836 Servo error amount where reference position return is possible

[Data type] Byte axis

[Unit of data] Detection unit

[Valid data range] 0 to 127

This parameter sets a servo error used to enable reference position return

in manual reference position return.

In general, set this parameter to 0. (When 0 is set, 128 is assumed as the

default.)

WARNING

When bit 0 of parameter No. 2000 is set to 1, a value ten

times greater than the value set in this parameter is used to

make the check.

Example:When the value 10 is set in this parameter, and bit

0 of parameter No. 2000 is set to 1, reference

position return operation is enabled when a servo

error of 100 or more occurs.
