Series 0i - Model A Connection manual (Function) Page 624

Connection manual (Function)
11. PROGRAM COMMAND
B–63503EN–1/01
608
5165 Percentage of the spindle speed to be changed when the tool is retracted without
an overload torque signal received
[Data type] Byte
[Unit of data] %
[Valid data range] 0 to 255
This parameter sets the percentage of the spindle speed to be changed
when the tool is retracted without the overload torque signal received in a
peck drilling cycle of a small diameter.
S2 = S1 d2 B 100
S1: Spindle speed to be chaged
S2: Spindle speed changed
d2 is set as a percentage.
5166 Percentage of cutting feedrate to be changed when the tool is retracted after an
overload torque signal is received
[Data type] Byte
[Unit of data] %
[Valid data range] 0 to 255
This parameter sets the percentage of the cutting feedrate to be changed
when the tool is retracted because the overload torque signal is received in
a peck drilling cycle of a small diameter.
F2 = F1 b1 B 100
F1: Cutting feedrate to be changed
F2: Changed cutting feedrate
b1 is set as a percentage.
5167 Percentage of the cutting feedrate to be changed when the tool is retracted without
an overload torque signal received
[Data type] Byte
[Unit of data] %
[Valid data range] 0 to 255
This parameter sets the percentage of the cutting feedrate tot be changed
when the tool is retracted without the overload torque signal received in a
peck drilling cycle of a small diameter.
F2 = F1 b2 B 100
F1: Cutting feedrate to be changed
F2: Changed cutting feedrate
b2 is set as a percentage.
