15. PMC CONTROL FUNCTION

771

Expansion workpiece number search signal

Workpiece

number

0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

0 0 0 0 0 0 0 0 0 0 0 0 0 1 1

0 0 0 0 0 0 0 0 0 0 0 0 1 0 2

0 0 0 0 0 0 0 0 0 0 0 0 1 1 3

...

1 0 0 1 1 1 0 0 0 0 1 1 1 0 9998

1 0 0 1 1 1 0 0 0 0 1 1 1 1 9999

Workpiece number 0 is used for special designation “no search”. Thus.

a workpiece number ranges from 1 to 9999.

These signals are enabled when parameter EPN (No. 3006#1) is 1. They

are used instead of work number search signals PN1 to PN16.

G009

#6 #5 #4

PN16

PN8

PN4

PN2

PN1

EPN7G024

EPN6

EPN5

EPN4

EPN3

EPN2

EPN1

EPN0

G025 EPN13 EPN12 EPN11 EPN10 EPN9 EPN8

3006

#6 #5 #4 #3 #2 #1

EPN

[Data type] Bit

EPN When a program number is specified, external work number search

signals are used as follows:

0 : Work number search signals (PN1 to PN16) are used.

1 : Extended work number search signals (EPN1 to EPN13) are used.

Number Message Description

059 PROGRAM NUMBER

NOT FOUND

In an external program number search

or external workpiece number search,

a specified program number was not

found. Otherwise, a program specified

for searching is being edited in back-

ground processing. Check the program

number and external signal. Or discon-

tinue the background eiting.

Signal address

Parameter

Alarm and Message
