9. SPINDLE SPEED FUNCTION
352
The table below lists the differences related to direct control of the spindle
control unit.
Spindle control unit for
spindle serial output
interface
Spindle control unit for
spindle analog output
interface
Parameters for
the spindle con-
trol unit
Specified as CNC parame-
ters
(4000 to 4351/S1, S2)
Used after being transferred
to the spindle control unit
Directly specified for the
spindle control unit
Control signal for
the spindle con-
trol unit
Connected to the PMC via
the CNC
G0070 to G0073 and F0045
to F0048:
Addresses for the first
spindle
G0074 to G0077 and F0049
to F0052:
Addresses for the second
spindle
Connected to the PMC via
an external contact
Spindle speed
command inter-
face
Digital data in a range from
0 to"maximum spindle mo-
tor speed
Analog voltage from 0 to
"10 V (excluding portion
for offset voltage adjust-
ment)
Position coder
interface
Connected to the CNC via
the spindle control unit
Connected directly to the
CNC
· Spindle control unit signals for the serial spindle
<G0070 to G0073> (input), <F0045 to F0048> (output)
→ for the first serial spindle
<G0074 to G0077> (input), <F0049 to F0052> (output)
→ for the second serial spindle
These addresses are on the CNC. Actually, however, they are input/output
signals for the spindle control unit for the serial spindle.
For details of the signals belonging to these addresses, refer to the
manuals for the serial spindle:
FANUC SERVO AMPLIFIER a series Descriptions (B–65162E)
FANUC AC SPINDLE MOTOR a series Descriptions (B–65152E)
FANUC SERVO MOTOR a series Maintenance Manual (B–65165E)
Signal
