B–63503EN–1/01

1. AXIS CONTROL

Bit 0 (ROTx) of parameter 1006 can be used to set each axis to a linear

axis or rotation axis. Bit 1 (ROSx) of parameter 1006 can be used to select

the rotation axis type, A or B, for each axis. See the explanation of the

parameters for details of types A and B.

When the roll over function is used, the values displayed for absolute

coordinates are rounded by the shift amount per rotation, as set in

parameter No. 1260. This can prevent coordinates for the rotation axis

from overflowing. Displayed values for relative coordinates are also

rounded by the angle corresponding to one rotation when bit 2 (RRLx) of

parameter No. 1008 is set to 1. The roll–over function is enabled by

setting bit 0 (ROAx) of parameter 1008 to 1.

For an absolute command, the coordinates after the tool has moved are

values rounded by the angle corresponding to one rotation set in

parameter No. 1260. The tool moves in the direction in which the final

coordinates are closest when bit 1 of parameter No. 1008 is set to 0. For

an incremental command, the tool moves the angle specified in the

command.

1.2.3

Specifying the Rotation

Axis

General
