B–63503EN–1/01

A. INTERFACE BETWEEN CNC AND PMC

843

Address

Refer-

ence

Item

series

Symbol Signal name

G074#0 Torque limit commandLOW signal (serial spindle) TLMLB f f 9.2

G074#1 Torque limit commandHIGH signal (serial spindle) TLMHB f f 9.2

G074#3,#2 Clutch/gear signal (serial spindle) CTH1B,CTH2B f f 9.2

G074#4 CCW command signal (serial spindle) SRVB f f 9.2

G074#5 CW command signal (serial spindle) SFRB f f 9.2

G074#6 Orientation command signal (serial spindle) ORCMB f f 9.2

G074#7 Machine ready completion signal (serial spindle) MRDYB f f 9.2

G075#0 Alarm reset signal (serial spindle) ARSTB f f 9.2

G075#1 Emergency stop signal (serial spindle) *ESPB f f 9.2

G075#2 Spindle select signal (serial spindle) SPSLB f f 9.2

G075#3 Power line switch completion signal (serial spindle) MCFNB f f 9.2

G075#4 Soft start stop cancel signal (serial spindle) SOCNB f f 9.2

G075#5 Signal for controllingvelocity integration (serial spindle) INTGB f f 9.2

G075#6 Output switch request signal (serial spindle) RSLB f f 9.2

G075#7 Power line status check signal (serial spindle) RCHB f f 9.2

G076#0 Orientation stop position change signal (serial spindle) INDXB f f 9.2

G076#1

Rotation direction command while changing the

orientation stop position signal (serial spindle)

ROTAB f f 9.2

G076#2

Short–distant movement command while changing the

orientation stop position signal (serial spindle)

NRROB f f 9.2

G076#3 Differential mode command signal (serial spindle) DEFMDB f f 9.2

G076#4 Analog override command signal (serial spindle) OVRIDB f f 9.2

G076#5

Incremental command external setting type orientation

signal (serial spindle)

INCMDB f f 9.2

G076#6

Main spindle MCC status signal while changing spindles

signal (serial spindle)

MFNHGB f f 9.2

G076#7

High–output MCC status signal while a magnetic sensor

(serial spindle)

RCHHGB f f 9.2

G077#0

Command for spindle orientaion with a magnetic sensor

(serial spindle)

MORCMB f f 9.2

G077#1 Slave operation command signal (serial spindle) SLVB f f 9.2

G077#2 Motor power stop signal (serial spindle) MPOFB f f 9.2

G078#0 to G079#3 SHA00 to SHA11 f f

G080#0 to G081#3

Spindle orientation external stop position command signal

SHB00 to SHB11 f f

9.12

G096#0 to #6 1% step rapid traverse override signal *HROV0 to *HROV6 f f 7.1.6.1

G096#7 1% step rapid traverse override select signal HROV f f 7.1.6.1

G098 Key code signal EKC0 to EKC7 f f 15.5

G100 +J1 to +J4 f f

G102

Feed axis and direction selection signal

-J1 to -J4 f f

3.1

G106 Mirror image signal MI1 to MI4 f f 1.2.5

G108 Each-axis machinelock signal MLK1 to MLK4 f f 5.3.1
