Series 0i - Model A Connection manual (Function) Page 443

Connection manual (Function)
B–63503EN–1/01
9. SPINDLE SPEED FUNCTION
427
#7 #6 #5 #4 #3 #2 #1 #0
1006 ROTx
[Data type] Bit axis
Type of controlled axis
0 : Linear axis
1 : Rotation axis
NOTE
Inch/metric conversion cannot be made to the rotation axis.
The machine coordinate values are rounded in 0 + O 360
deg. Automatic reference position return (G28, G30) is
made in the manual reference position return direction and
the move amount does not exceed one rotation.
Set 1 as the rotation axis to the Cs contour control axis.
1020 Name of the axis used for programming for each axis
[Data type] Byte axis
Set the name of the program axis for each control axis, with one of the
values listed in the following table:
Axis
name
Set
value
Axis
name
Set
value
Axis
name
Set
value
Axis
name
Set
value
X 88 U 85 A 65 E 69
Y 89 V 86 B 66 – –
Z 90 W 87 C 67 – –
NOTE
1 In the T series, when G code system A is used, neither U,
V, nor W can be used as an axis name. Only when G code
system B or C is used, U, V, and W can be used as axis
names.
2 The same axis name cannot be assigned to more than one
axis.
3 When the second auxiliary function is valid, address B
cannot be used as an axis name. In the T series, when
address A or C is used, set parameter CCR (No. 3405#4)
to 0.
4 If you use letter E as an axis name in format FS10/11, be sue
to use address F in the major–axis direction lead command
for equal–lead threading (G32).
Any axis name can be used for Cs contour control axis except for above
limitation.
