A. INTERFACE BETWEEN CNC AND PMC
833
Group
Refer-
ence
item
M
series
T
series
Address Signal nameSymbol
MMLK All-axis machine lock check signal F004#1 f f 5.3.1
MORA1A
Signal for completion of spindle orientationwith a
F046#6 f f
MORA1B
Signal for completion of spindle orientationwith a
magnetic sensor (serial spindle)
F050#6 f f
9.2
MORA2A
SIgnal for approximate spindle orientationwith a
F046#7 f f
MORA2B
SIgnal for approximate spindle orientationwith a
magnetic sensor (serial spindle)
F050#7 f f
9.2
MORCMA
Command for spindle orientaion with a magnetic
G073#0 f f
MORCMB
Command for spindle orientaion with a magnetic
sensor (serial spindle)
G077#0 f f
9.2
MP1,MP2
Manual handle feed amount selection signal
(incrementalfeed signal)
G019#4,#5 f f 3.2
MP1O Software operator's panel signal(MP1) F076#0 f f 12.1.14
MP2O Software operator's panel signal(MP2) F076#1 f f 12.1.14
M
MPOFA G073#2 f f
MPOFB
Motor power stop signal (serial spindle)
G077#2 f f
9.2
MRDYA G070#7 f f
MRDYB
Machine ready signal (serial spindle)
G074#7 f f
9.2
MREF
Manual reference position return selection check
signal
F004#5 f f 4.1
MRMT DNC operationselect check signal F003#4 f f 5.9
MSBK Single block check signal F004#3 f f 5.3.3
MTCHIN TEACH IN select check signal F003#7 f f 2.6
MV1 to MV4 Axis moving signal F102 f f 1.2.4
MVD1 to MVD4 Axis moving direction signal F106 f f 1.2.4
NPOS1 to NPOS4 Position display neglect signal G198 f f 12.1.10
N NRROA
Short–distant movement command while changing
G072#2 f f
NRROB
Short–distant movement command while changing
the orientation stop position signal (serial spindle)
G076#2 f f
9.2
OFN0 to OFN5,OFN6 Tool offset number select signal
G039#0 to
#5,G040#0
f - 14.4.2
OP Automaticoperation signal F000#7 f f 5.1
ORARA F045#7 f f
ORARB
Orientationcompletionsignal (serial spindle)
F049#7 f f
9.2
ORCMA G070#6 f f
O ORCMB
Orientationcommand signal (serial spindle)
G074#6 f f
9.2
OUT0 to OUT7
Software operator's panel general-purpose switch
signal
F072 f f 12.1.14
OVC Override cancel signal G006#4 f f 7.1.6.3
OVCE Override cancellation signal (PMC axis control) G150#5 f f 15.1
OVRIDA G072#4 f f
OVRIDB
Analog override command signal (serial spindle)
G076#4 f f
9.2
