B–63503EN–1/01

14. MEASUREMENT

699

Number Message Description

015 TOO MANY AXES COM-

MANDED

In the block including the command for

the skip function (G31 P99/P98), to be

executed under the control of the

torque limit reach signal, no axis move

command is specified, or two or more

axes are specified.

In a single block, specify one axis only.

244 P/S ALARM When the skip function to be executed

under the control of the torque limit

reach signal is enabled, an error value

(32767) that exceeds the maximum re-

turn value that can be handled with a

single distribution is detected before in-

put of the torque limit reach signal.

Retry the processing after changing the

axis feedrate, torque limit, or other

conditions.

CAUTION

1 Specify a torque limit before G31 P99/P98. If G31 P99/P98

is executed with no torque limit specified, the move

command is executed without a skip operation.

2 When G31 P99 is specified, the SKIP signal causes a skip

operation. However, avoid using the high–speed skip

operation.

3 Before specifying G31 P99/P98, cancel tool–tip radius

compensation with G40.

4 Set the SKF bit (bit 7 of parameter No. 6200) to 0 to disable

the dry run, override, and automatic

acceleration/deceleration functions for the G31 skip

command.

OPERATOR’S MANUAL

(For Lathe) (B–63504EN)

TORQUE LIMIT SKIP

Alarm and message

Caution

Reference item
