B–63503EN–1/01

6. INTERPOLATION FUNCTION

235

Typical values range from 0.000 to 35.999.

[Classification] Output signal

[Function] Informs the PMC that the machine is in the polygon turning mode.

[Output condition] The polygon synchronization signal is set to logical “1” by the polygon

turning mode command (G51.2) and stays at “1” during the polygonal

turning mode.

The signal is reset to logical “0” by the polygon turning mode reset

command (G50.2) or a reset. It stays at logical “0” when the machine is

not in the polygonal turning mode.

· Other signals (related to the tool rotation axis)

→ Some signals related to the CNC controlled axis used as the tool

rotation axis may be made ineffective depending on whether the

machine is in the polygonal turning mode.

For these signals, read the note in operator’s manual (for lathe).

PSYNF063

#6 #5 #4 #3 #2 #1 #0

PLZ7600

#6 #5 #4 #3 #2 #1 #0

[Data type] Bit

PLZ Synchronous axis using G28 command

0: Returns to the reference position in the same sequence as the manual

reference position return.

1: Returns to the reference position by positioning at a rapid traverse.

The synchronous axis returns to the reference position in the same

sequence as the manual reference position return when no

return–to–reference position is performed after the power is turned

on.

7610 Control axis number of tool rotation axis for polygon turning

[Data type] Byte

[Valid data range] 1, 2, 3, . . . number of control axes

This parameter sets the control axis number of a rotation tool axis used for

polygon turning.

Signal

Polygon synchronization

under way signal

PSYN

<F063#7>

Signal address

Parameter
