Series 0i - Model A Connection manual (Function) Page 690

Connection manual (Function)
13. INPUT/OUTPUT OF DATA
B–63503EN–1/01
674
#7
3202
#6 #5 #4
NE9
#3 #2 #1 #0
NE8
[Data type] Bit type
NE8 Editing of subprograms with program numbers 8000 to 8999
0 : Not inhibited
1 : Inhibited
The following edit operations are disabled:
(1)Program deletion (Even when deletion of all programs is specified,
programs with program numbers 8000 to 8999 are not deleted.)
(2)Program output (Even when outputting all programs is specified,
programs with program numbers 8000 to 8999 are not output.)
(3)Program number search
(4)Registered program editing
(5)Program registration
(6)Program collation
(7)Displaying programs
NE9 Editing of subprograms with program numbers 9000 to 9999
0 : Not inhibited
1 : Inhibited
The following edit operations are disabled:
(1)Program deletion (Even when deletion of all programs is specified,
programs with program numbers 9000 to 9999 are not deleted.)
(2)Program punching (Even when punching of all programs is
specified, programs with program numbers 9000 to 9999 are not
punched.)
(3)Program number search
(4)Registered program editing
(5)Program registration
(6)Program collation
(7)Displaying programs
