10. TOOL FUNCTIONS

B–63503EN–1/01

530

TL128G047

TL64

TL32

TL16

TL08

TL04

TL02

TL01

TLRSTG048 TLRSTI TLSKP

*TLV7G049 *TLV6 *TLV5 *TLV4 *TLV3 *TLV2 *TLV1 *TLV0

G050 *TLV9 *TLV8

F064

#6 #5 #4 #3 #2

TLCHI

TLNW

TLCH

8132

#6 #5 #4 #3 #2 #1 #0

TLF

NOTE

When this parameter has been set, the power must be

turned off before operation is continued.

[Data type] Bit

TLF Specifies whether to use tool life management, as follows :

0 : Not to use.

1 : Use.

#7 #6 #5 #4 #3 #2 #1 #0

6800

M6T IGI

SNG GRS SIG LTM GS2 GS1

[Data type] Bit

GS1, GS2 This parameter sets the combination of the number of tool life groups

which can be entered, and the number of tools which can be entered per

group as shown in the table below.

M series T series

GS2 GS1

Group count Tool count Group count Tool count

0 0 1– 16 1– 16 1– 16 1– 16

0 1 1– 32 1– 8 1– 32 1– 8

1 0 1– 64 1– 4 1– 64 1– 4

1 1 1–128 1– 2 1– 16 1– 16

LTM Tool life

0 : Specified by the number of times

1 : Specified by time

Signal address

Parameter
