5. TOOL FUNCTION (T FUNCTION)
B–63683EN/01
90
#7
RP8TF244
#6
RP7T
#5
RP6T
#4
RP5T
#3
RP4T
#2
RP3T
#1
RP2T
#0
RP1T
RP16TF245 RP15T RP14T RP13T RP12T RP11T RP10T RP9T
16680 Position of machine zero point 1 on T–axis
16681 Position of machine zero point 2 on T–axis
16682 Position of machine zero point 3 on T–axis
16683 Position of machine zero point 4 on T–axis
16684 Position of machine zero point 5 on T–axis
16685 Position of machine zero point 6 on T–axis
16686 Position of machine zero point 7 on T–axis
16687 Position of machine zero point 8 on T–axis
16688 Position of machine zero point 9 on T–axis
16689 Position of machine zero point 10 on T–axis
16690 Position of machine zero point 11 on T–axis
16691 Position of machine zero point 12 on T–axis
16692 Position of machine zero point 13 on T–axis
16693 Position of machine zero point 14 on T–axis
16694 Position of machine zero point 15 on T–axis
16695 Position of machine zero point 16 on T–axis
[Data type] Two–word
[Unit of data] Least command increment for T–axis
[Valid data range] 0 to 99999999
WARNING
If the servo–off signal is used under T–axis control, setting
the *FLWU signal (G007, #7) to 0 causes the follow–up
function to operate at servo–off. This sets the TIE and RP1T
to RP16T signals to 0. T–axis indexing may not be executed
correctly. To prevent such problems from occurring, set the
*FLWU (G007, #7) signal to 1.
