Series 16i/18i/160i/180i - PB Connection manual (Function) Page 42

Connection manual (Function)
2. FUNCTION SPECIFICATIONS THAT DIFFER
FROM THE M series
B–63683EN/01
32
The DEN signal is set to 1 also in the following states:
D Punch completion wait state (*PFIN or *NFIN) for the press function
once all axial movements have been completed
D Completion wait state (FIN) for the external operation function once
all axial movements have been completed
The DEN signal can also be used for the external operation function. If
a specification is made to set the press start signal (PF) to 1 before the
completion of positioning, the external operation function signal (EF) is
also set to 1 before the completion of positioning. The DEN signal should
be used as a gate signal for starting operation after movement when the
external operation function is used.
NOTE
When the 2nd auxiliary function is provided, the A/B macro
function cannot be used to store and call a specified pattern.
The internal processing for the following M codes is executed,
independently of the AFL signal:
D Forming mode, forming mode cancel
D Nibbling mode, nibbling mode cancel
D Workpiece clamp, workpiece unclamp
D Switching between punch mode and laser mode
These M codes can be output, even when the AFL signal is set to 1, by
setting the PMA bit accordingly (bit 5 of parameter 16001).
2.7
AUXILIARY
FUNCTION
2.7.1
Distribution End Signal
Difference
2.7.2
2nd Auxiliary Function
2.7.3
Auxiliary Function
Lock
Difference
