Series 16i/18i/160i/180i - PB Connection manual (Function) Page 185

Connection manual (Function)
B–63683EN/01
11. CONTROL FUNCTION
175
[Classification] Input signal
[Function] This signal suspends automatic operation.
[Operation] This signal has the same effect as feed hold signal *SP (G008#5). The
CNC reads the input data directly, however, not via the PMC. This signal
is valid when bit 4 (SPR) of parameter No. 16002 is set to 1.
[Classification] Output signal
[Function] This signal notifies the PMC that automatic operation has been
suspended.
[Output condition] This signal has the same effect as feed hold lamp signal SPL (F000#4).
This signal, however, is set to 1 when automatic operation is suspended by
feed hold signal B (*SPR).
[Classification] Output signal
[Function] This signal notifies the PMC that the reset key on the CRT/MDI panel has
been pressed.
[Output condition] This signal is set to 1 while the reset key on the CRT/MDI panel is held
down; the signal reverts to 0 when the reset key is released.
11.1
FEED HOLD SIGNAL
B/FEED HOLD LAMP
SIGNAL B
Feed hold signal B
*SPR <X008#5>
Feed hold lamp signal B
SPRL <F230#4>
11.2
RESET KEY SIGNAL
RSTSW <F239#5>
