9. SAFETY ZONE AREA EXTENSION
B–63683EN/01
160
16942 X dimension of tool area 13 for the safety zone function
16943 Y dimension of tool area 13 for the safety zone function
16944 X dimension of tool area 14 for the safety zone function
16945 Y dimension of tool area 14 for the safety zone function
16946 X dimension of tool area 15 for the safety zone function
16947 Y dimension of tool area 15 for the safety zone function
16948 X dimension of tool area 16 for the safety zone function
16949 Y dimension of tool area 16 for the safety zone function
[Data type] Two–word
Increment system IS–A IS–B Unit
Millimeter machine 0.01 0.001 mm
Inch machine 0.001 0.0001 inch
[Valid data range] 0 to 99999999
The parameters set 16 tool areas for the safety zone function.
Refer to parameters No. 16517 to No. 16532 and No. 16551 to 16558.
NOTE
A tool area is selected by signals SZTS0 to SZTS3 input
from a PMC machine.
16950 Width of workpiece holder 5 along the X–axis for automatic setting
16951 Width of workpiece holder 6 along the X–axis for automatic setting
16952 Width of workpiece holder 7 along the X–axis for automatic setting
16953 Width of workpiece holder 8 along the X–axis for automatic setting
[Data type] Two–word
Increment system IS–A IS–B Unit
Millimeter machine 0.01 0.001 mm
Inch machine 0.001 0.0001 inch
[Valid data range] 0 to 99999999
Each of the parameters specifies the width of a workpiece holder along the
X–axis for the automatic setting of a safety zone by an external signal.
The parameter values correspond to safety zones 5 to 8, specified in
parameters 16930 to 16941, respectively.
Refer to parameters No.16540 to No.16543.
When automatic setting is executed, these parameters must be set.
[Unit of data]
[Unit of data]
