8. SAFETY ZONE CHECK
B–63683EN/01
154
Number Message Contents
4800 ZONE : PUNCHING INHIBITED 1 When a safety zone check was executed, a punch command was
specified in area 1 where punching is inhibited.
4801 ZONE : PUNCHING INHIBITED 2 When a safety zone check was executed, a punch command was
specified in area 2 where punching is inhibited.
4802 ZONE : PUNCHING INHIBITED 3 When a safety zone check was executed, a punch command was
specified in area 3 where punching is inhibited.
4803 ZONE : PUNCHING INHIBITED 4 When a safety zone check was executed, a punch command was
specified in area 4 where punching is inhibited.
4810 ZONE : ENTERING INHIBITED 1 +X When a safety zone check was executed, the machine moving in the
positive X direction entered area 1 into which entry is inhibited.
4811 ZONE : ENTERING INHIBITED 1
–X
When a safety zone check was executed, the machine moving in the
negative X direction entered area 1 into which entry is inhibited.
4812 ZONE : ENTERING INHIBITED 2 +X When a safety zone check was executed, the machine moving in the
positive X direction entered area 2 into which entry is inhibited.
4813 ZONE : ENTERING INHIBITED 2
–X
When a safety zone check was executed, the machine moving in the
negative X direction entered area 2 into which entry is inhibited.
4814 ZONE : ENTERING INHIBITED 3 +X When a safety zone check was executed, the machine moving in the
positive X direction entered area 3 into which entry is inhibited.
4815 ZONE : ENTERING INHIBITED 3
–X
When a safety zone check was executed, the machine moving in the
negative X direction entered area 3 into which entry is inhibited.
4816 ZONE : ENTERING INHIBITED 4 +X When a safety zone check was executed, the machine moving in the
positive X direction entered area 4 into which entry is inhibited.
4817 ZONE : ENTERING INHIBITED 4
–X
When a safety zone check was executed, the machine moving in the
negative X direction entered area 4 into which entry is inhibited.
4830 ZONE : ENTERING INHIBITED 1 +Y When a safety zone check was executed, the machine moving in the
positive Y direction entered area 1 into which entry is inhibited.
4831 ZONE : ENTERING INHIBITED 1
–Y
When a safety zone check was executed, the machine moving in the
negative Y direction entered area 1 into which entry is inhibited.
4832 ZONE : ENTERING INHIBITED 2 +Y When a safety zone check was executed, the machine moving in the
positive Y direction entered area 2 into which entry is inhibited.
4833 ZONE : ENTERING INHIBITED 2
–Y
When a safety zone check was executed, the machine moving in the
negative Y direction entered area 2 into which entry is inhibited.
4834 ZONE : ENTERING INHIBITED 3 +Y When a safety zone check was executed, the machine moving in the
positive Y direction entered area 3 into which entry is inhibited.
4835 ZONE : ENTERING INHIBITED 3
–Y
When a safety zone check was executed, the machine moving in the
negative Y direction entered area 3 into which entry is inhibited.
4836 ZONE : ENTERING INHIBITED 4 +Y When a safety zone check was executed, the machine moving in the
positive Y direction entered area 4 into which entry is inhibited.
4837 ZONE : ENTERING INHIBITED 4
–Y
When a safety zone check was executed, the machine moving in the
negative Y direction entered area 4 into which entry is inhibited.
4870 AUTO SETTING FEED ERROR The feed rate of safety zone auto setting is other than the parameter
value (No. 16538, No. 16539).
4871 AUTO SETTING PIECES ERROR In safety zone auto setting, the safety zone pieces are not correct. Or the
position detector has gone wrong, please tell your machine tool builder.
4872 AUTO SETTING COMMAND
ERROR
M code, S code or T code is specified with safety zone auto setting
command (G32).
G32 is specified in the nibbling mode, in the cutter compensation, in
the rotation mode or the scaling mode.
8.8
ALARM AND
MESSAGE
