Series 16i/18i/160i/180i - PB Connection manual (Function) Page 120

Connection manual (Function)
5. TOOL FUNCTION (T FUNCTION)
B–63683EN/01
110
The unregistered T code signal is output if a T code which is not registered
using the tool data registration screen is specified during automatic
operation.
The PMC can monitor this signal and issue an alarm if it is output, for
example, to prevent punching from being performed according to a
command specifying an unregistered tool.
[Classification] Output signal
[Function] Notifies the PMC that a T code which is not registered in the tool data
registration screen has been specified.
[Output condition] This signal is output if a T code which is not registered in the tool data
registration screen is specified during automatic operation when bit 5
(TNA) of parameter No. 16262 is set to 1.
The output timing is the same as that for a T code signal. The state of the
signal is maintained in the same way as for a T code signal.
#7
F242
#6 #5 #4 #3 #2 #1 #0
URTCD
5.7
UNREGISTERED
T CODE SIGNAL
General
Signal
Unregistered T code
signal URTCD <F242#0>
Signal address
