Series 16i/18i/160i/180i - PB Connection manual (Function) Page 14

Connection manual (Function)
1. LIST OF FUNCTIONS
B–63683EN/01
4
No.
Whether
supported
Item
4 Reference position establishment
4.1 Manual reference position return f
4.2 Setting the reference position without dogs f
4.3 Reference position shift f
4.4 Reference position return ∆: See chapter 2
4.5 2nd reference position return/3rd, 4th
reference position return
∆: See chapter 2
4.6 Floating reference position return f
4.7 Butt–type reference position setting ×
4.8 Linear scale with absolute addressing
reference marks
f
4.9 Extended function of the linear scale with
absolute addressing reference marks
f
5 Automatic operation
5.1 Cycle start/feed hold ∆: See chapter 2
5.2 Reset and rewind f
5.3 Testing a program
Machine lock ∆: See chapter 2
Dry run f
Single block ∆: See chapter 2
Manual handle retrace ×
5.4 Manual absolute on/off ∆: ”Manual absolute
off” is
unavailable.
5.5 Optional block skip/addition of optional block
skip
f
5.6 Sequence number comparison and stop f
5.7 Program restart ×
5.8 Tool retraction and return ×
5.9
Exact stop/exact stop mode/cutting mode f
Tapping mode ×
5.10 Balance cut ×
5.11 DNC operation f
5.12 Manual intervention and return ×
5.13 Retraction for rigid tapping ×
