Series 16i/18i/160i/180i - PB Connection manual (Function) Page 196

Connection manual (Function)
11. CONTROL FUNCTION
B–63683EN/01
186
When using seven–level velocity loop gain switching, use these
parameters to set the velocity loop integral gains. (Equivalent to
parameter No. 2043)
Only the settings for the X– and Y–axes are valid.
16835 Velocity loop proportional gain for level 1
16836 Velocity loop proportional gain for level 2
16837 Velocity loop proportional gain for level 3
16838 Velocity loop proportional gain for level 4
16839 Velocity loop proportional gain for level 5
16840 Velocity loop proportional gain for level 6
16841 Velocity loop proportional gain for level 7
[Data type] Word axis
[Valid data range] –1 to 32767
When using seven–level velocity loop gain switching, use these
parameters to set the velocity loop proportional gains. (Equivalent to
parameter No. 2044)
Only the settings for the X– and Y–axes are valid.
16842 Position gain switching speed (ordinary machining)
16843 Position gain switching speed (nibbling)
[Data type] Word
[Valid data range] –1 to 32767
Set the maximum speed at which the position gain is doubled during
automatic operation in ordinary machining mode and nibbling mode.
(Equivalent to parameter No. 2028)
Only the settings for the X– and Y–axes are valid.
These parameters are valid when bit 5 (VCG) of parameter No. 16051 is
set to 1 and either or both of bits 7 (KLV) and 2 (N3S) of parameter No.
16050 are set to 1.
