Series 16i/18i/160i/180i - PB Connection manual (Function) Page 222

Connection manual (Function)
B. ALARM LIST
B–63683EN/01
APPENDIX
212
Number ContentsMessage
4823 ZONE : ENTERING INHIBITED 7
–X
When a safety zone check was executed, the machine moving in the
negative X direction entered are 7 into which entry is inhibited.
4824 ZONE : ENTERING INHIBITED 8 +X When a safety zone check was executed, the machine moving in the
positive X direction entered are 8 into which entry is inhibited.
4825 ZONE : ENTERING INHIBITED 8
–X
When a safety zone check was executed, the machine moving in the
negative X direction entered are 8 into which entry is inhibited.
4830 ZONE : ENTERING INHIBITED 1 +Y When a safety zone check was executed, the machine moving in the
positive Y direction entered area 1 into which entry is inhibited.
4831 ZONE : ENTERING INHIBITED 1
–Y
When a safety zone check was executed, the machine moving in the
negative Y direction entered area 1 into which entry is inhibited.
4832 ZONE : ENTERING INHIBITED 2 +Y When a safety zone check was executed, the machine moving in the
positive Y direction entered area 2 into which entry is inhibited.
4833 ZONE : ENTERING INHIBITED 2
–Y
When a safety zone check was executed, the machine moving in the
negative Y direction entered area 2 into which entry is inhibited.
4834 ZONE : ENTERING INHIBITED 3 +Y When a safety zone check was executed, the machine moving in the
positive Y direction entered area 3 into which entry is inhibited.
4835 ZONE : ENTERING INHIBITED 3
–Y
When a safety zone check was executed, the machine moving in the
negative Y direction entered area 3 into which entry is inhibited.
4836 ZONE : ENTERING INHIBITED 4 +Y When a safety zone check was executed, the machine moving in the
positive Y direction entered area 4 into which entry is inhibited.
4837 ZONE : ENTERING INHIBITED 4
–Y
When a safety zone check was executed, the machine moving in the
negative Y direction entered area 4 into which entry is inhibited.
4838 ZONE : ENTERING INHIBITED 5 +Y When a safety zone check was executed, the machine moving in the
positive Y direction entered are 5 into which entry is inhibited.
4839 ZONE : ENTERING INHIBITED 5
–Y
When a safety zone check was executed, the machine moving in the
negative Y direction entered are 5 into which entry is inhibited.
4840 ZONE : ENTERING INHIBITED 6 +Y When a safety zone check was executed, the machine moving in the
positive Y direction entered are 6 into which entry is inhibited.
4841 ZONE : ENTERING INHIBITED 6
–Y
When a safety zone check was executed, the machine moving in the
negative Y direction entered are 6 into which entry is inhibited.
4842 ZONE : ENTERING INHIBITED 7 +Y When a safety zone check was executed, the machine moving in the
positive Y direction entered are 7 into which entry is inhibited.
4843 ZONE : ENTERING INHIBITED 7
–Y
When a safety zone check was executed, the machine moving in the
negative Y direction entered are 7 into which entry is inhibited.
4844 ZONE : ENTERING INHIBITED 8 +Y When a safety zone check was executed, the machine moving in the
positive Y direction entered are 8 into which entry is inhibited.
4845 ZONE : ENTERING INHIBITED 8
–Y
When a safety zone check was executed, the machine moving in the
negative Y direction entered are 8 into which entry is inhibited.
4854 ZONE : ENTERING INHIBITED 5 Z A command executed in the laser mode brings the Z–axis height into
the approach forbidden area 5. (FS16i–LP: Safety zone check type
B)
4855 ZONE : ENTERING INHIBITED 6 Z A command executed in the laser mode brings the Z–axis height into
the approach forbidden area 6. (FS16i–LP: Safety zone check type
B)
