Series 16i/18i/160i/180i - PB Connection manual (Function) Page 11

Connection manual (Function)
B–63683EN/01
1. LIST OF FUNCTIONS
1
1
LIST OF FUNCTIONS
For details of connections that are not related to the punch press function,
refer to the “FANUC Series 16i/18i/21i/160i/180i/210i/160is/180is/
210is–MODEL B CONNECTION MANUAL (FUNCTION)”
(B–63523EN–1). Most of the functions described in B–63523EN–1 can
be used with the FANUC Series 16i/18i/160i/180i–PB. The remainder
either cannot be used with the FANUC Series 16i/18i/160i/180i–PB or
have different specifications when used with the FANUC Series
16i/18i/160i/180i–PB. The table below indicates whether the functions
described in B–63523EN–1 can be used with the FANUC Series
16i/18i/160i/180i–PB. For an explanation of the differences in the
specifications, see Chapter 2.
The table below lists the functions.
The following symbols are used in the table:
f : The function can be used with the FANUC Series
16i/18i/160i/180i–PB.
× : The function cannot be used with the FANUC Series
16i/18i/160i/180i–PB.
∆ : The function has different specifications when used with the
FANUC Series 16i/18i/160i/180i–PB.
No. Item
Whether
supported
1 Axis control
1.1 Number of Controlled axes f
1.2 Setting each axis
Name of axes ∆: See chapter 2
Increment system ∆: See chapter 2
Specifying the rotation axis ∆: See chapter 2
Controlled axes detach f
Outputting the movement state of an axis f
Mirror image ∆: See chapter 2
Follow–up ∆: See chapter 2
Servo off (mechanical handle) f
Position switch f
High–speed position switch f
Direction–sensitive high–speed position
switch
f
