Series 16i/18i/160i/180i - PB Connection manual (Function) Page 117

Connection manual (Function)
B–63683EN/01
5. TOOL FUNCTION (T FUNCTION)
107
#7
16281
#6 #5 #4
PC4
#3 #2
OY4
#1
OX4
#0
[Data type] Bit
This parameter is valid when the function to set tool data is specified. In
the following description, n represents the number of tools to be stored.
OX4 For the tool position compensation value along the X–axis:
0 : n four–byte values can be stored. The valid data range is 0 to
"99999999.
1 : n two–byte values can be stored. The valid data range is –32768 to
+32767.
OY4 For the tool position compensation value along the Y–axis:
0 : n four–byte values can be stored. The valid data range is 0 to
"99999999.
1 : n two–byte values can be stored. The valid data range is –32768 to
+32767.
PC4 For the punching count of individual tools:
0 : n four–byte values can be stored. The valid data range is 0 to
99999999.
1 : n two–byte values can be stored. The valid data range is 0 to 65536.
#7
16282
#6
MTS
#5
CMT
#4 #3 #2
MOY
#1
MOX
#0
[Data type] Bit
This parameter is valid when the function used to set tool data is specified.
In the following description, m represents the number of subtools stored
for a multi–tool.
MOX The tool position compensation value along the X–axis for a multi–tool
is:
0 : Not stored.
1 : Stored. See the description of the MX4 bit (bit 1 of parameter 16283).
MOY The tool position compensation value along the Y–axis for a multi–tool
is:
0 : Not stored.
1 : Stored. See the description of the MY4 bit (bit 2 of parameter 16283).
CMT The tool numbers for a multi–tool:
0 : Are the magazine number plus subtool number. When this is selected,
m equals n (number of tools stored).
1 : Consist of the Magazine number and subtool number, which are
separately stored. (m 2–byte numbers)
MTS The graphic tool figure for a multi–tool is:
0 : Not stored.
1 : Stored. (n 13–byte data items)
NOTE
This bit is valid when the CMT bit (bit 5 of parameter 16282)
is set to 1.
