Series 16i/18i/160i/180i - PB Connection manual (Function) Page 50

Connection manual (Function)
2. FUNCTION SPECIFICATIONS THAT DIFFER
FROM THE M series
B–63683EN/01
40
Table 2.13 G code list (2/2)
System A
System B Group Meaning
G57 G57 Work coordinates system 4 selection
G58 G58 14 Work coordinates system 5 selection
G59 G59 Work coordinates system 6 selection
G61 G61 Exact stop mode
G62 G62
15
Automatic corner override
G64 G64
Continuous cutting mode
G65 G95 00 Custom macro simple call
G66 G96 Custom macro modal call
G67 G97
12
Custom macro modal call cancel
G68 G68 Circular nibbling
G69 G69 Linear nibbling
G70 G70 Positioning & press off
G72 G72 Standard point command
G73 G75 Multi–piece machining command X
G74 G76 00 Multi–piece machining command Y
G75 G27 Automatic repositioning
G76 G28 Line at angle
G77 G29 Arc
G78 G36 Grid I
G79 G37 Grid II
G84 G84 Coordinate rotating on
G85 G85
16
Coordinate rotating off
G86 G66 Share proof
G87 G67 Square
G88 G78
00
Radius
G89 G79 Cut at angle
G90 G90
Absolute command
G91 G91
03
Incremental command
G92 G92 Coordinate system setting
G98 G98
00
Coordinate system setting (Multi–piece machining)
