Series 16i/18i/160i/180i - PB Connection manual (Function) Page 41

Connection manual (Function)
B–63683EN/01
2. FUNCTION SPECIFICATIONS THAT DIFFER
FROM THE M series
31
The T–axis and C–axis jog override can be set by input signals that differ
from the conventional input signals, G010 and G011 (*JV0 to *JV15).
[Classification] Input signal
[Function] Selects the T–axis and C–axis jog feedrate.
*JVT1 *JVT2 Override value of T and C axis
1 1 25%
1 0 50%
0 1 75%
0 0 100%
#7
G233
#6 #5 #4 #3 #2 #1
*JVT2
#0
*JVT1
#7
16052
#6 #5
TJG
#4 #3 #2 #1 #0
[Data type] Bit
TJG The jog override signals for the T–axis and C–axis (G233, #0 and #1) are:
0 : Not used.
1 : Used.
WARNING
When the ISA increment system is being used, this function
cannot be used because a sufficient level of precision
cannot be attained.
This function cannot be used when high–speed press
control (HSP bit, bit 0 of parameter 16000) is applied.
In advanced preview control mode, programmable
parameter input (G10) must not be used.
2.6.4
T–axis, C–axis Jog
Override Signal
General
*JVT1, *JVT2
<G233#0, #1>
Signal address
Parameter
2.6.5
Advanced Preview
Control
