Series 16i/18i/160i/180i - PB Connection manual (Function) Page 35

Connection manual (Function)
B–63683EN/01
2. FUNCTION SPECIFICATIONS THAT DIFFER
FROM THE M series
25
#7
KL2j16844
#6
PT2j
#5
TM2j
#4
LP2j
#3 #2 #1 #0
[Data type] Bit axis
LP2j For rapid traverse during automatic operation, seven–level servo loop
gain switching, based on the positioning distance, for position control for
each axis is:
0 : Disabled.
1 : Enabled.
This parameter is valid when KL2j is set to 1.
See also the explanations of parameter Nos. 16882 to 16888.
TM2j For constant positioning time control, the times set in parameter Nos.
16878 to 16881 are:
0 : Used as is.
1 : Doubled.
PT2j Constant positioning time control is:
0 : Disabled.
1 : Enabled.
This parameter is valid when KL2j is set to 1.
See also the explanations of parameters No. 16878 to 16881.
KL2j For rapid traverse during automatic operation, seven–level rapid traverse
rate and time constant switching, based on the positioning distance, for
each axis is:
0 : Disabled.
1 : Enabled.
See also the explanations of parameter Nos. 16845 to 16877.
