Series 16i/18i/160i/180i - PB Connection manual (Function) Page 61

Connection manual (Function)
B–63683EN/01
3. PRESSING FUNCTION
51
In addition to the circular or linear nibbling according to the G68 or G69
command, this control can perform nibbling by M function. In other
words, it can execute nibbling in the blocks from a block with the M code
of nibbling mode to a block with the M code of nibbling mode cancel as
shown below.
M12; (M code of nibbling mode)
. . . . . . . . . . . .
. . . . . . . . . . . .
Nibbling is done in these blocks.. . . . . . . . . . . .
. . . . . . . . . . . .
. . . . . . . . . . . .
. . . . . . . . . . . .
M13; (M code of nibbling mode cancel)
In this manual, the M code of nibbling mode is described as M12, while
the M code of the nibbling mode cancel is described as M13. However,
since these M codes may be different from those specified above in certain
machine tool builders, you are requested to read these M codes
correspondingly according to the manual prepared by these machine tool
builders.
Don’t use this nibbling by M function in a different way other than
specified in this manual, since there are certain restriction about its use.
WARNING
Each of the M codes for nibbling mode and nibbling mode
cancel must be commanded in a single block.
3.4
NIBBLING BY
M FUNCTION
