Series 16i/18i/160i/180i - PB Connection manual (Function) Page 217

Connection manual (Function)
B–63683EN/01
A. CNC AND PMC INTERFACEAPPENDIX
207
Address Reference
item
SymbolName
G230#3 Manual press start signal MPS 3.5.3
G230#4 Continuous manual press signal MNS 3.5.3
G230#5 Press stop signal neglect EPE 3.5.8
G230#6 Two–step selection for nibbling signal SNP 3.5.9
G230#7 External operation function select signal EFS 3.7
G231#0,#1 Multi–piece machining setting signal MLP1,MLP2 4.2.3
G231#2 Nibbling three–level switching signal SNP2 11.7
G232#0–#3 Selection signal for tool area of safety zone SZTS0–SZTS3 8.6
G232#4 Punch enable signal WDC 8.6
G232#5 Automatic safety zone setting request signal SAFRQ 8.5.2
G232#6 Avoid operation signal ACZEXE 10.2
G232#7 Tool escape completion signal WHALC 10.1
G233#0,#1 T–axis, C–axis jog override signal *JVT1*JVT2 2.6.4
G233#5 T command neglect signal TNG 5.3.1
G233#6 Tool change signal TCNG 5.3.2
G233#7 C–axis unconnected signal CFDC 6.3.2
G234–G237 T code display signal TI00–TI31 5.3.4
G240#0 Forming mode selection signal FORMS 3.5.11
G240#3 Manual tool change signal MNTCHG 5.8
G241#0–#6 Rapid traverse time constant override signals RTCOV0–RTCOV6 11.5
G247#0–#3 Soft thermal monitor axis selection signals OVAX0–OVAX3 11.8
G248#1 Pre–issued T code complete signal BTFIN 5.5
G248#3 Multi–piece machining skip signal MGSKP 11.5
X004#0 Skip signal SKIP 2.11.1
X004#1 Workpiece holder position detector signal SAFZ 8.5
X004#4 Press start waiting signal B PFWB 3.5.6
X004#5 Punch finish signal for 1–cycle press *PFIN 3.5.1
X004#6 Nibbling finish signal *NFIN 3.5.2
X004#7 Press stop signal *PE 3.5.1
X008#5 Feed hold signal B *SPR 11.1
Y004#1 Nibbling signal NBL 3.5.2
Y004#2 Press start signal PF 3.5.1
Y004#3 Press start signal B PFB 3.5.7
