Series 16i/18i/160i/180i - PB Connection manual (Function) Page 215

Connection manual (Function)
B–63683EN/01
A. CNC AND PMC INTERFACEAPPENDIX
205
Group Reference
item
AddressNameSymbol
O
OVAX0–OVAX3 Soft thermal monitor axis selection signals G247#0–#3 11.8
OVC0–OVC6 Soft thermal monitor signals F243#0–#6 11.8
P
PF Press start signal Y004#2 3.5.1
PFB Press start signal B Y004#3 3.5.7
PFL Press start lock signal G230#0 3.5.4
PFW Press start waiting signal G230#1 3.5.6
PFWB Press start waiting signal B X004#4 3.5.6
PN00–PN31 Number of punches signal F234–F237 5.3.5
PTLCH Tool expired signal F232#0 2.9.2
R
RP1T–RP16T T–axis machine zero point position signals F244–F245 5.3.6
RSTSW Reset key signal F239#5 11.2
RTCOV0–RTCOV6 Rapid traverse time constant override signals G241#0–#6 11.5
RVSARV Multi–piece machining skip ready signal F225#0 11.5
RVSSKE Multi–piece machining skip completion signal F225#2 11.5
S
SAFEXE Safety zone setting ready signal F231#6 8.2
SAFRQ Automatic safety zone setting request signal G232#5 8.5.2
SAFZ Workpiece holder position detector signal X004#1 8.5
SC1,SC2 C–axis control status signal F233#0,#1 6.2
SKIP Skip signal X004#0 2.11.1
SNP Two–step selection for nibbling signal G230#6 3.6.9
SNP2 Nibbling three–level switching signal G231#2 11.7
SPRL Feed hold lamp signal B F230#4 11.1
SZN1–SZN8 Safety zone interference area signals F228#0–#7 9
SZT1–SZT16 In safety zone signal F240–F241#0–#3
F238#4–#7
8.6
SZTS0–SZTS3 Selection signal for tool area of safety zone G232#0–#3 8.6
T
TCNG Tool change signal G233#6 5.3.2
TI00–TI31 T code display signal G234–G237 5.3.4
TIE Turret indexing completion signal F232#6 5.3.3
TNG T command neglect signal G233#5 5.3.1
W
WDC Punch enable signal G232#4 8.2
WDDO Punch forbidden area entered signal F231#7 8.2
WHAL Tool escape signal F231#5 10.1
WHALC Tool escape completion signal G232#7 10.1
