Series 16i/18i/160i/180i - PB Connection manual (Function) Page 159

Connection manual (Function)
B–63683EN/01
8. SAFETY ZONE CHECK
149
SZI Data set on the safety zone setting display is:
0 : Invalidated.
1 : Validated.
SOF In the safety zone check, tool position compensation is:
0 : Not considered.
1 : Considered.
16505 Positive X coordinate for safety zone 1
16506 Negative X coordinate for safety zone 1
16507 Y coordinate for safety zone 1
16508 Positive X coordinate for safety zone 2
16509 Negative X coordinate for safety zone 2
16510 Y coordinate for safety zone 2
16511 Positive X coordinate for safety zone 3
16512 Negative X coordinate for safety zone 3
16513 Y coordinate for safety zone 3
16514 Positive X coordinate for safety zone 4
16515 Negative X coordinate for safety zone 4
16516 Y coordinate for safety zone 4
[Data type] Two–word
Increment system IS–A IS–B Unit
Millimeter machine 0.01 0.001 mm
Inch machine
0.001 0.0001 inch
[Valid data range] 0 to "99999999
Each set of the parameters specify safety zone 1, 2, 3, or 4.
NOTE
1 The values set for zone #n must be smaller than those set
for zone #(n + 1). (n: 1 to 3)
2 Zeros must be specified for zones which need not be
specified.
[Unit of data]
