Series 16i/18i/160i/180i - PB Connection manual (Function) Page 214

Connection manual (Function)
A. CNC AND PMC INTERFACE
B–63683EN/01
APPENDIX
204
Group Symbol Name Address Reference
item
*
*JVT1*JVT2 T–axis, C–axis jog override signal G233#0,#1 2.6.4
*NFIN Nibbling finish signal X004#6 3.5.2
*PE Press stop signal X004#7 3.5.1
*PFIN Punch finish signal for 1–cycle press X004#5 3.5.1
*SPR Feed hold signal B X008#5 11.1
A ACZEXE Avoid operation signal G232#6 10.2
B
BT00–BT31 Pre–issued T code signal F246–F249 5.5
BTF Pre–issued T code strobe signal F232#1 5.5
BTFIN Pre–issued T code complete signal G248#1 5.5
C
CFDC C–axis unconnected signal G233#7 6.3.2
CMOK Multiple tool indexing complete signal F232#5 5.4
CPEN Coupling enable signal F232#4 6.3.2
CPS 1–cycle press select signal G230#2 3.5.2
D
DPF Press start assistance signal F230#6 3.5.5
DSPF Press start auxiliary signal B F230#5 3.5.10
E
EFS External operation function select signal G230#7 3.7
EPE Press stop signal neglect G230#5 3.5.8
F FORMS Forming mode selection signal G240#0 3.5.11
L LASMOD Laser mode set signal F239#6 11.3
M
MIE Multiple tool indexing signal F232#7 5.4
MLP1,MLP2 Multi–piece machining setting signal G231#0,#1 4.2.3
MNS Continuous manual press signal G230#4 3.5.3
MPS Manual press start signal G230#3 3.5.3
MGSKP Multi–piece machining skip signal G248#3 11.5
MNTCHG Manual tool change signal G240#3 5.8
MNTNOD Manual tool change in–progress signal F233#3 5.8
N
NBL Nibbling signal Y004#1 3.5.2
NBLE Nibbling completion signal F230#7 3.5.2
NRTCD Unregistered T code signal F242#0 5.7
A.2.2
List of Signals in the
Order of Symbols
