Series 16i/18i/160i/180i - PB Connection manual (Function) Page 37

Connection manual (Function)
B–63683EN/01
2. FUNCTION SPECIFICATIONS THAT DIFFER
FROM THE M series
27
[Valid data range] 0 to "120
Set the time during which the press start signal PF is set to 1 prior to the
end of the positioning corresponding to each positioning distance (PF
early output function).
These parameters are valid for those axes for which bit 7 (KL2j) of
parameter No. 16844 is set to 1.
16864 Rapid traverse rate for level 1
16865 Rapid traverse rate for level 2
16866 Rapid traverse rate for level 3
16867 Rapid traverse rate for level 4
16868 Rapid traverse rate for level 5
16869 Rapid traverse rate for level 6
16870 Rapid traverse rate for level 7
[Data type] Two–word axis
Increment system Unit of data Valid data range
Millimeter machine 1 mm/min 30 to 240000
Inch machine 0.1 inch/min 30 to 96000
Rotary axis 1 deg/min 30 to 240000
Set the rapid traverse rate for each positioning distance, for each axis.
These parameters are valid for those axes for which bit 7 (KL2j) of
parameter No. 16844 is set to 1.
16871 Rapid traverse time constant for level 1
16872 Rapid traverse time constant for level 2
16873 Rapid traverse time constant for level 3
16874 Rapid traverse time constant for level 4
16875 Rapid traverse time constant for level 5
16876 Rapid traverse time constant for level 6
16877 Rapid traverse time constant for level 7
[Data type] Word axis
[Unit of data] ms
[Valid data range] 8 to 4000
Set the rapid traverse time constant for each positioning distance, for each
axis.
These parameters are valid for those axes for which bit 7 (KL2j) of
parameter No. 16844 is set to 1.
[Unit of data]
[Valid data range]
