Series 16i/18i/160i/180i - PB Connection manual (Function) Page 180

Connection manual (Function)
10. WORKPIECE HOLDER INTERFERENCE
AVOIDANCE FUNCTION
B–63683EN/01
170
[Classification] Input signal
[Function] This signal posts the completion of tool escape.
[Operation] When this signal is set to 1, the WHAL signal is set to 0.
[Classification] Output signal
[Function] This signal posts notification that the tool may interfere with the
workpiece holder during tool positioning.
[Output condition] This signal is set to 1 in the following cases:
(1)When, during automatic operation, a positioning operation that may
cause the tool to interfere with the workpiece holder is started
(2)When, during manual operation, the tool enters the interference area
of a workpiece holder
This signal is set to 0 in the following cases:
(1)When the WHALC signal, set to 1, is received
(2)In the reset state
CAUTION
If, during manual operation, the tool enters an interference
area, for example, this signal is set to 0 only after the tool is
moved out of the interference area.
[Classification] Input signal
[Function] This signal specifies whether to perform avoidance operation according
to the type B specification.
[Operation] When this signal is set to 1, avoidance operation is performed as part of
a positioning operation that may cause the tool to interfere with the
workpiece holder.
10.4
SIGNAL
Tool escape completion
signal WHALC <G232#7>
Tool escape signal
WHAL <F231#5>
Avoidance operation
signal
ACZEXE <G232#6>
