Series 16i/18i/160i/180i - PB Connection manual (Function) Page 36

Connection manual (Function)
2. FUNCTION SPECIFICATIONS THAT DIFFER
FROM THE M series
B–63683EN/01
26
16845 Distance D1 to level 1 (in mm)
16846 Distance D2 to level 2 (in mm)
16847 Distance D3 to level 3 (in mm)
16848 Distance D4 to level 4 (in mm)
16849 Distance D5 to level 5 (in mm)
16850 Distance D6 to level 6 (in mm)
16851 Distance D1 to level 1 (in inches)
16852 Distance D2 to level 2 (in inches)
16853 Distance D3 to level 3 (in inches)
16854 Distance D4 to level 4 (in inches)
16855 Distance D5 to level 5 (in inches)
16856 Distance D6 to level 6 (in inches)
[Data type] Two–word axis
Increment system IS–A IS–B Unit
Metric input 0.01 0.001 mm
Inch input 0.001 0.0001 inch
Rotary axis 0.01 0.001 deg
[Valid data range] 0 to 99999999
When using seven–level rapid traverse rate and time constant switching
based on the positioning distance, use these parameters to set the
positioning distance for each axis.
These parameters are valid for those axes for which bit 7 (KL2j) of
parameter No. 16844 is set to 1.
16857 Time during which PF is set to 1 prior to the end of positioning for level 1
16858 Time during which PF is set to 1 prior to the end of positioning for level 2
16859 Time during which PF is set to 1 prior to the end of positioning for level 3
16860 Time during which PF is set to 1 prior to the end of positioning for level 4
16861 Time during which PF is set to 1 prior to the end of positioning for level 5
16862 Time during which PF is set to 1 prior to the end of positioning for level 6
16863 Time during which PF is set to 1 prior to the end of positioning for level 7
[Data type] Byte axis
[Unit of data] ms
[Unit of data]
