2. FUNCTION SPECIFICATIONS THAT DIFFER
FROM THE M series
B–63683EN/01
14
#7
UVW16200
#6
ABM
#5 #4 #3 #2 #1 #0
[Data type] Bit
ABM To store and call a pattern, addresses A and B:
0 : Are used.
1 : Are not used. (The A and B axes can be used.)
UVW To execute a macro function, addresses U, V, and W:
0 : Are used.
1 : Are not used. (The U, V, and W axes can be used.)
Two increment systems, IS–A and IS–B, are supported.
When the T–axis or C–axis control function is used, the T–axis or C–axis
automatically becomes the rotation axis.
The following are not inverted:
D Direction of manual operation
D Motion toward the reference position in an automatic reference
position return
D Repositioning
D Motion of tool position compensation and C–axis position
compensation
CAUTION
If the value of the T–axis mirror image is set to 1, the amount
of travel is inverted, resulting in incorrect turret indexing.
(Never specify this setting.)
2.1.2
Increment System
Difference
2.1.3
Specifying the Rotation
Axis
Difference
2.1.4
Mirror Image
Difference
