Series 16i/18i/160i/180i - PB Connection manual (Function) Page 20

Connection manual (Function)
1. LIST OF FUNCTIONS
B–63683EN/01
10
No.
Whether
supported
Item
12.2 Edit
Part program storage length f
Number Of registered programs f
Memory protection key f
Password function f
Background editing f
Playback ×
Conversational programming with graphic
function
f
Program copy between two paths ×
13 Input/output of data
13.1 Reader/puncher interface f
13.2 Remote buffer f
13.3 DNC1 interface ∆: Specification for
M series
13.4 DNC2 interface ∆: Specification for
M series
13.5 External i/o device control f
13.6 Simultaneous input and output operations f
13.7 External program input f
13.8 Data input/output functions based on the I/O
Link
f
13.9 Screen hard copy function f
14 Measurement
14.1 Tool length measurement ×
14.2 Automatic tool length measurement/Automatic
tool offset
×
14.3 Skip function
Skip function ∆: See chapter 2
High–speed skip signal f
Multi–step skip ×
Torque limit skip ×
Continuous high–speed skip function ×
Skip function for EGB axis ×
