Series 16i/18i/160i/180i - PB Connection manual (Function) Page 212

Connection manual (Function)
A. CNC AND PMC INTERFACE
B–63683EN/01
APPENDIX
202
Function ItemAddressSymbolName
Turret axis control (T axis control)
T command neglect signal TNG G233#5 5.3.1
Tool change signal TCNG G233#6 5.3.2
Turret indexing completion signal TIE F236#6 5.3.3
T code display signal TI00–TI31 G234–G237 5.3.4
Number of punches signal PN00–PN31 F234–F237 5.3.5
T–axis machine zero point position
signals
RP1T–RP16T F244–F245 5.3.6
T–code pre–issue function
Pre–issued T code complete signal BTFIN G248#1 5.5
Pre–issued T code strobe signal BTF F232#1 5.5
Pre–issued T code signal BT00–BT31 F246–F249 5.5
Unregistered T code signal Unregistered T code signal NRTCD F242#0 5.7
T–axis, C–axis jog override T–axis, C–axis jog override signal *JVT1*JVT2 G233#0,#1 2.6.4
Rapid traverse time constant override Rapid traverse time constant override
signals
RTCOV0–
RTCOV6
G241#0–#6 11.5
Switching the punching and laser
modes
Laser mode set signal LASMOD F239#6 11.3
Press function
Press stop signal *PE X004#7 3.5.1
Punch finish signal for 1–cycle press *PFIN X004#5 3.5.1
Press start signal PF Y004#2 3.5.1
Nibbling finish signal *NFIN X004#6 3.5.2
Nibbling signal NBL Y004#1 3.5.2
1–cycle press select signal CPS G230#2 3.5.2
Nibbling completion signal NBLE F230#7 3.5.2
Continuous manual press signal MNS G230#4 3.5.3
Manual press start signal MPS G230#3 3.5.3
Press start lock signal PFL G230#0 3.5.4
Press start assistance signal DPF F230#6 3.5.5
Press start waiting signal PFW G230#1 3.5.6
Press start waiting signal B PFWB X004#4 3.5.6
Press start signal B PFB Y004#3 3.5.7
Press stop signal neglect EPE G230#5 3.5.8
Two–step selection for nibbling signal SNP G230#6 3.5.9
Press start auxiliary signal B DSPF F230#5 3.5.10
Forming mode selection signal FORMS G240#0 3.5.11
